I’ve got a Behringer RD-6 Analog Drum Machine and it’s battery powered! I’ve seen a number of video reviews of this machine and the reviewer always seems to say “It’s not battery powered, so you can’t easily take it with you…” But I’m here to tell you that you can take it with you (just like Steve Albini did with his Roland TR-606) and below I’ll show you how.
Here’s what you need! A Behringer RD-6 Analog Drum Machine. Any color will do. Mine is red.
A battery pack that will hold 6 AA batteries. Each battery is 1.5 volts, so 6 of them is 9 volts. (And no, a standard 9 volt battery won’t work due to the low amperage it can put out.) I had some lying around that were like this but some have connectors on them like these. As long as they have bare wires at the end, you’re good. If they do have a connector on the end you may need to chop it off. (More on that later.)
You’ll need a 2.1mm Barrel Power Jack. I usually buy a pack of them. You only need one, so find one, or buy one, or buy a bunch and have spares. (You won’t need the matching receptacle plugs. At least not for this project.)
Important! All of the barrel jacks I’ve purchased have positive in the center and negative on the outside of the barrel. In the world of musical things (well, guitar pedals at least) negative is on the center, and positive is on the outside of the barrel.
Here’s the back of the RD-6. You can see the symbol showing negative in the center. Note that it also shows 300 milliamps. A 9 volt battery is 500 milliamps, so it will work for a while, but not long. The power supply Behringer gives you is 670 milliamps, but it’s not a battery, it plugs into a wall socket.
Right so we need to… reverse the polarity! Luckily it’s as simple as switching the wires around. Normally red is positive and black is negative, but we’re switching those. Make red negative and black positive.
Here’s mine. Now, it’s worth noting that I checked all of this with a multimeter. I’d advise you to do the same. Double check your work. If you don’t know what you’re doing, ask someone for help. This probably voids your warranty, and I cannot be held responsible for what you do. On with the show!
Oh, you’ll also need batteries! Any AA batteries will do, but rechargeable are preferred, at least by me. I’m a fan of the Eneloop rechargeable batteries. I’ve got some I bought ten years ago that still work. Grab a charger and 4 batteries and, um… 4 more because you need a total of 6 batteries.
Okay, stick it all together and you get a battery powered drum machine. Boom. Tsk. Boom. Tsk. I haven’t testing how long a set of batteries will last, but I’ll add that to the list of things to do.
Now, it’s not as nice as internal batteries that are built into the case, and if I actually use this on a regular basis I might think about adding in some hook & loop to attach the battery pack to the side. It might be better to use two 3 AA battery packs wires together, since those would have a flat back that could be attached to the RD-6.
