2019.04.17

octonoise-5573

For this year’s WMSE Art & Music event, I created a new board I call OctoNoise. It’s an eight note piano featuring capacitive touch pads, LEDs, a Teensy LC microcontroller, and some fine woodworking. This is somewhat similar to last year’s piece.

octonoise-laser

You may know me for my work with decagons, but I also work with octagons, and this pattern is known as a 16 cell and it worked well for my design which utilizes 8 touch pads and 8 LEDs.

octonoise-5579

I’m not an amazing woodworker, but after laser cutting wood I can typically sand it, stain it, and add some polyurethane. At least it looks (somewhat) nice. I didn’t alter the bottom piece, and I just left it as a square, the way I received it from WMSE. My original design for this piece (over a year ago) was a bit different, but I wanted this to match the style of last year’s WMSE piece (and I was a bit rushed getting this done.)

octonoise-5583

The OctoNoise features and on/off switch, which is handy because it runs on batteries. I can’t tell you how many times I’ve made electronic things for myself and not included and on/off switch. It’s nice to have one! When you turn it on the touch pads calibrate for about 5 seconds. There’s a startup sound that happens during calibration. (I added a note about that on the back of the piece.)

octonoise-5576

There’s a “somewhat” hidden control knob on the side that ajusts the delay between notes. The way the code is written, it plays one note at a time, but you can alter that to very quickly (or slowly) oscillate between multiple notes. You can get some interesting variances in sound by turning the knob.

Note that it is difficult to turn the knob while also touching the pads to make sound. This is by design, as it’s also difficult (if not damn near impossible without using various parts of your body) to play all the notes at once. This was done to encourage collaboration and playfulness.

octonoise-5589

Here’s a side view. The height was determined by the speaker that was chosen. Once again we’ve put the electronics on display as part of the piece rather than hide them inside an enclosure. They are mean to be celebrated! (Each wire has a label showing what it connects to, if needed.)

octonoise-5591

Here’s the Teensy LC, which runs the code. The board has built it capacitive touch pins, which make writing the code fairly easy. The notes used are C5, D5, E5, F5, G5, A5, B5, C6. This is real piano, and you can play actual songs. I based the code on a project I did for Brown Dog Gadgets a while back. You can check out their Touch Piano on Github.

octonoise-5594

This device also contains an built-in amp with a volume control. Again, a sometimes rare feature in the things I build. Often amps require 12 volts and that’s not always fun to deal with, but I’ve found some that work on variable voltages from 3 to 12 volts, so running them at the same voltage as a microcontroller becomes very easy.

octonoise-3d-parts

Besides all the wood and electronics, there are some 3D printed parts that pull it all together. The on/off switch, delay control, amp, and battery holder all have their own 3D printed part that they attach to and then easily attach to the wood with some #4 screws. Once again, things are left “open” to celebrate rather than hide the electronics.

octonoise-standoff

The other 3D printed pieces are the custom standoffs that raise the top piece above the bottom piece to (partially) enclose the electronics. I created a 2D profile from the original artwork used to laser etch & cut the piece to create the correct angle. I then extruded that design to make the tall standoffs and printed 8 of them.

As usual, I encourage you to check out my Instagram account if you’re interested in seeing confusing photos of these sorts of things coming together.

Oh, one thing I forgot to mention. I liked this piece so much, I made another one so I could keep one for myself. As the old saying goes “If you’re gonna make one, make two!” So I did.

Finally, here are some videos, including one showing me playing both of them at once, which might never happen again!

2018.03.31

wmse-art-music-0951

When I heard WMSE was doing a fundraising event called Art & Music and was looking for artists to contribute, I wanted in. I got in touch with them and got a blank 12″x12″ board. I’ve done some of these art boards before, once for The Eisner American Museum of Advertising & Design and once for a friend of mine. (And while it’s not a board, I also made this NoiseBowl last year.) Besides myself, I also managed to get most of the people I work with at Brinn Labs to make boards, and a few people at Milwaukee Makerspace also made them.

wmse-art-music-0932

This one is a litte more special to me though… WMSE went on the air in 1981, and while I don’t remember when I actually started listening to it (though I do have my brother to thank) I grew up with WMSE. They played the music I wanted to hear (at least on Wednesday nights when I was in high school.) They introduced me to weird and crazy stuff, and I even got to be a guest on air a few times (and they’ve managed to play a few songs from bands I was in.)

wmse-art-music-0952

Since I’ve been screwing around with making noise with Arduinos in sculptural form I thought I’d continue that obsession practice once again. I’ve been working on a four step sequencer for work, so that’s what this is…

wmse-art-music-0974

If it wasn’t for the stain and attention to fit and finish in creating this piece, it might look like some of my work you’d find inside a museum exhibit. We tend to make a lot of devices that produce sound. (We typically don’t go to great lengths to make them “pretty” though, since they always live inside cabinets and are not seen by the public.

wmse-art-music-0957

wmse-panel-render

Here’s the design for the one cut piece I made. It’s the control panel/user interface, which holds the power switch, potentiometers, and the LEDs. I actually used the CNC router instead of the laser cutter to make it. (Don’t ask why!) It also took some careful drill press operations to get things just right. There was also a lot of sanding involved. (Again, don’t ask.)

wmse-standoff-legs

There are some 3D printed pieces as well. The standoffs used for the speaker, and to hold the control panel in place. They are similar to ones I’ve used before and before, but of course the beauty of 3D printing is that I can change the design each time to match the speaker and hardware used. (Parametric, FTW!)

wmse-art-music-0979

Here’s a short video that demonstrates the noise that this thing makes. The first four knobs adjust the pitch for the four steps, with the fifth knob used to adjust tempo, and the top right knob as a volume control. The LEDs light up showing each step of the sequencer.

wmse-art-music-0983

I also decided when I started to build this that I really wanted one for myself. While I love seeing my artwork go out into the world, sometimes I miss it. Since I was building one, I thought it would be easy to build a second one. Well, it was (fairly) easy, but it was also time consuming. I also had this idea that if anything went wrong, I’d have a backup. Nothing really went wrong, but I did finish the one for WMSE about week before I finished the one for me.

wmse-art-music-0984

If you’re ever curious about the process I go through when building these sorts of things, you might want to head over to Instagram and follow me there. For instance, I posted a photo there… and another, and another, and a video

wmse-art-music-0985

And then I posted more, and then I probably posted even more. So yeah, Instagram tends to be my “in process” photo & video place.

wmse-art-music-0986

And if you’re not hip to Instagram you might find a photo or two (or three) over on Facebook. Not as much shows up there, but we’re still friends, right?

wmse-art-music-0988

wmse-art-music-0989

Enjoy the show!

wmse-art-music-0998

Note: The piece sold for $510! I’m really pleased I was able to support WMSE with this, and I’m thankful a bunch of people liked it enough to bid on it.

2016.07.14

The Sonic Titan

You probably remember The Sonic Titan, which had its debut at Bay View Gallery Night. The details concerning the construction of The Sonic Titan were shrouded in mystery, just a hazy cloud of unknowns, but no more! Here is the story of The Making of The Sonic Titan!

The concept for The Sonic Titan was kicking around in my head for a long time. When Neil Gershenfeld talks about making, there’s this idea of personalization, and producing products for a market of one person. The Sonic Titan may have a market of one person, myself, and I’m fine with that.

speaker-box-01

The physical manifestation of The Sonic Titan started with this speaker cabinet I saw in the alley on my way home one night. One of my neighbors was throwing it away. I always like to build upon the detritus and waste of society, so I grabbed it.

speaker-box-02

As an electronics nerd, I loved the giant capacitor bank circuit thingies on the back. I considered using them, but it didn’t fit the aesthetics of the piece.

speaker-box-03

I grabbed a screwdriver, hammer, and pry bar and got to work tearing the speaker cabinet apart.

speaker-box-04

Mmmmmm, delicious fiberglass insulation! People really knew how to DIY speaker cabinets in the olden days!

speaker-box-05

Why not add some roofing shingles to your speaker cabinet? Glue then down with some weird industrial adhesive to keep them in place, because acoustical properties.

speaker-box-06

I got the speaker out in one piece. I didn’t end up using this speaker, but I’ve still got it on the scrap pile for a future project.

inside-doom

A fully formed cabinet emerges! I must have forgotten to take photos of the construction process. Basically after I broke apart the cabinet I rebuilt it into the size and shape I wanted with the help of the table saw, drill, and a bunch of screws. (Oh, and there was a fun adventure with the jig saw for the speaker holes.) I also grabbed some old scrap wood my brother dropped off at my garage about two years ago. The wood had all sorts of weird slots cut into it. (Thanks, Brother!)

Anyway, the above photos shows how everything is lovingly stuffed into the cabinet. There was no careful thought or long consideration about putting things in there. It was basically “jam it in and make it fit” the whole way. Mostly.

speakers-spades

Spade terminals come in handy for this sort of thing, and I had some handy, so I used them. The speakers came from Milwaukee Makerspace, which is always full of all sorts of weird old junk. The large fender washers are actually the scrap pieces from when I drill out Aluminum boxes to make USB controllers. Reuse!

raspberry-pi

Hey look, it’s a Raspberry Pi! Yes the “Doom Box” is Linux-powered, which seems appropriate for so many reasons. But seriously, folks… I love Linux. It allows me to do things like this quickly, easily, and at a low cost. Open source is a wonderful thing.

The Raspberry Pi is secured in place by… gravity? Yeah, it’s just sitting there. It’s got a Micro USB cable for power, and a 1/8″ cable for audio out.

power-supply

There’s a 12 volt power supply, this provides power to the audio amp, and to the Raspberry Pi. Wait, the Raspberry Pi needs 5 volts, not 12 volts… what!?

buck-converter

Oh look, there’s a buck converter which takes the 12 volts and knocks it down to 5 volts. These are handy when you don’t want to have two power supplies. Just split the 12 volt power and run to the converter and you get your 5 volts. Sweet!

screw-terminals

There’s a few of these screw terminal blocks. This one feeds the 5 volts from the converter to the Micro USB cable that had one end cut off. Just use the red and black wires from the USB cable for power… no signal wires needed!

audio-amp-01

Here’s the audio amp. It’s got spade connectors all over. Two for the 12 volt power, and 4 for the two speakers. I’m pretty sure I screwed this down to the board. Oh yeah, I did, we’ll get to that later…

audio-amp-02

It’s a Pyle cheapie audio amplifier. Nothing fancy or super-loud, but I had it in the shop so I used it. The cover was removed because I had an idea to mount it right up to the front and use the integrated volume potentiometer and add my own wooden knob. That worked until I broke things…

audio-pot

…so there’s a potentiometer that got added in to replace the one I broke. And it’s not a dual pot, just a single, and probably not the right resistance. When things break and you’ve got a deadline you grab whatever you’ve got available and get things done. (At least I do, or I try to.) Wires are delicately soldered because deadline.

greeble-slot-01

Some of the greebles were put into place to cover the gaps that were created when the cabinet was built because I didn’t have quite enough wood to do it right. I call the greebles a “feature”.

greeble-slot-02

This little greeble works well to stuff the extra cables into. See, “features”!

greeble-slot-03

And this greeble closes up the gap at the bottom… (Note: hard drive magnets are great for keeping random screws in one place!)

greeble-slot-04

And over here there’s a lovely gap for the power cord to exit. Mind the gap! Use the gap! Love the gap!

Is it mere coincidence the photo above and the Dopesmoker art below share a similar color palette? Probably… or… maybe not!?!?

dopesmoker-01

Check out that stoner caravan! I hope they are enjoying their journey! They should have a Doom Box to listen to!

vinyl-mask

I used Bauhaus 93 as the typeface that came close to matching the Sleep logo I liked, and made a few pieces of vinyl which were put on the wood so I could use them as stencils and spray paint on the name and labels. I like vinyl and stencils and paint. They work well together!

Wait, wasn’t there something about Linux? Of course there was! After I had the Raspberry Pi up and running with Raspbian I added mpg123 for playing the audio:

sudo apt-get install mpg123

I then wrote a long and complex script to start the audio playing and keep it playing forever by using a loop. Here’s the long and complex script:

#!/bin/bash
mpg123 --loop -1 /home/pi/Dopesmoker.mp3

I saved that script and then set it to run after bootup by adding a call to it in the /etc/rc.local file, right before the exit line.


/bin/bash /boot/playaudio.sh
exit 0

And that’s how I built The Sonic Titan. I hope you enjoyed the journey.

2016.06.12

The Sonic Titan

The Sonic Titan was created for Bay View Gallery Night in June 2016 and was displayed at Milwaukee Makerspace.

The Sonic Titan

Similar to the piece I created last year, The Sonic Titan has a musical connection, which is fitting for Bay View Gallery Night which is “A celebration of local art, music, business and community.”

The Sonic Titan

You can find out more about this device/object/thing by checking out the project page for The Sonic Titan.

2011.06.15

Turntable.fm

Damn… this turntable.fm thing is a bit addictive!

Dave provided a fistful of awesome when he posted about it, and it probably helps that we were in bands together and liked a lot of the same stuff.

Turntable.fm uses Flash (urgh) and the search isn’t that great, but you and some friends who are into the same genres can have a good time taking turns “spinning discs” as it were.

Fun times!
