Our old (dumb) pal Pizza Bagel Bot didn’t spring from the oven fully baked… far from it! Why, I’ll have you know I spent nearly an hour carefully crafting a block of wood and a delicious meal into a whirling cheesy disaster!

PBB Bottom

I started with a nice block of wood and drilled a few holes to mount the motors. The motors are these Pololu 120:1 Mini Plastic Gearmotors. These were the only “high-tech” thing I used. Just under $12 for two motors.

PBB w/ Motors

There were zip ties involved. And hot glue was added later. Of course. Oh, I did solder some wires onto the motor terminals. I was worried that might also be “high-tech” but whatever. I wired them up so that it would just go in circles instead of forwards (or backwards) because going out of bounds means you lose the match. (Note: The zip ties are from Harbor Freight. There should be bonus points for that.)

Control Knobs

Now, for the wheels… I actually designed laser-cut wheels that fit nicely on these motor shafts, but… high-tech! Instead I dug through the basement workshop until I found these old control knobs from Radio Shack. They have a little set screw, and I figured I could screw them tight to the D-shaft. Perfect! Almost!

Control Knobs

The outer rim part was too big, and they did not fit. A little time on the grinder took care of that… I consider the grinder decidedly low-tech. (At some point I considered just putting a wheel on the grinder and using that as my robot… maybe next time!)

Control Knob

Boom! 5 minutes later, the smell of melty plastic, and I had two “wheels” which would be all wobbly because they didn’t center correctly on the D-shaft. No matter.

PBB  Assembly

Wheels are on, and the wires are twisted together, but not soldered, in case I want to reverse the wiring or something. It’s starting to look good. If you squint real hard you might mistake this for an actual not-dumb robot!

I seem to be missing some photos, but at some point I decided the square shape was no good, so I used a coping saw (hand-powered!) to cut the corners. (Literally!) I then needed something to hold the pizza bagel in place…

PBB Bottom

Nails are good for holding things in place. They also split wood. I split the wood. No matter, because… hot glue.

Pizza Bagel Bot

I also added this “high-tech” battery holder, which was a whopping 79 cents… Oh, the alligator clips were taken from some jumper wires I melted at some point. It’s not the volts, it’s the amps, kids! The batteries are AA and I’ve had them for years.

PBB Bottom

Oh yeah, the screws! Typically a robot will have a caster wheel or two, but at $1.99 each, and needing two of them… over-budget! (I could have 3D printed one but… high-tech!) The screws are not drilled into the wood the same amount because, me. This helps it wobble more unevenly. On purpose. Obviously.

Pizza Bagel Bot

Wow, look at that beautiful robotic platform. In about an hour. And I probably got distracted for part of that hour. The only thing missing is a delicious pizza bagel.

Pizza Bagel Bot

Mission Accomplished!

Don’t forget to check out the video, which at least one critic described as “mesmerizing”. Also, if you’ve got any good pizza bagel recipes, post them in the comments!


Pizza Bagel Bot

Our friends down at Pumping Station: One in Chicago have taken a cue from Hebocon and are holding a Dumb Robot Competition for Dummies tonight.

I am a dummy! (Or at least I can pretend to be one…)

Even though I’ve built functional robots, I tried really hard to build a dumb robot that is terrible. The result is “Pizza Bagel Bot” which you see here. (I used no digital fabrication in the building of PBB.)

I’m sure this will strike fear into the hearts of all who challenge Pizza Bagel Bot, so beware! And be aware.

I’ll provide more details about “PBB” in the coming days, but for now, enjoy this video proof of the mayhem of cheese and sauce that will be unleashed tonight!
